CNC Coolants - Water-Soluble Cutting Oils for CNC Machining

CNC Coolant - Water-Soluble Cutting Oils for CNC Machining

High-performance CNC coolant is essential for precision machining. The right cutting coolant controls heat, improves finish quality, and extends tool and machine life. Here you’ll find water-soluble cutting oils (also called soluble cutting oils or cutting oil water-soluble concentrates) - the most common CNC machining coolants used in metalworking today.

Why Use CNC Coolant

• Cooling: removes heat from the tool–workpiece zone for stable dimensions and longer tool life.
• Lubrication: lowers friction for smoother cutting and improved surface finish.
• Chip removal: flushes chips away to prevent re-cutting and tool wear.
• Clean operation: water-based emulsions reduce smoke, odor, and residue compared with neat oils.

Types of CNC Coolants (Water-Soluble Cutting Oils)

These are the main coolant families introduced on our Metalworking Fluids page - focused here only on the soluble types used in CNC machining.

Semi-Synthetic Coolants

Blend of mineral oil and synthetic additives. Excellent for mixed materials and general CNC use - good corrosion control, chip evacuation, and finish quality.

Fully Synthetic Coolants

Contain no mineral oil. Offer superior heat transfer, low foam, and long sump life. Ideal for high-speed or high-pressure CNC systems.

Vegetable / Ester-Based Coolants

Biodegradable water-soluble cutting oils derived from esters. Provide strong lubrication and corrosion protection while being more environmentally responsible.

Advanced Polymer-Based Coolants

Modern synthetic formulas without mineral oil. Deliver excellent temperature control, low bacterial growth, and high chemical stability for demanding CNC applications.

Choosing the Best Coolant for CNC Machines

For most CNC milling and turning, choose a semi-synthetic or fully synthetic CNC coolant with low foam and high stability. For aluminum and stainless, select a coolant labeled for mixed alloys. For heavy cutting, tapping, or forming, consider switching to machining oils for extra lubricity.

Maintenance Tips

• Mix with water to the manufacturer’s ratio - typically 6-8% for standard work, up to 10–12% for heavy-duty cutting.
• Use a refractometer to monitor concentration and adjust with premix water.
• Maintain water hardness in the mid-range; too soft increases foam, too hard destabilizes emulsions.
• Keep tanks clean, remove tramp oil, and replace filters on schedule.
