1/2" Dia. Mini Solid Carbide Boring Bar, DCMT 21.5, Right Hand

Name: E08K-SDUCR-2 - 1/2" Dia. Mini Solid Carbide Boring Bar, DCMT 21.5, Right Hand
Brand: EASYCUT
SKU: E08K-SDUCR-2
Price: 443.71 CAD
Availability: InStock

E08K-SDUCR-22 unit in stock

0.500" shank with a ground clamping flat, 5.000" overall length, 93° lead angle. Bores from 0.728" diameter. DCGT inserts of the same size also fit. No through-coolant; Torx clamping screw included, T-8 key not. The carbide shank is about three times stiffer than steel and holds size at overhangs where a steel bar chatters.

CA$422.58 excl. taxes

Retail price as of 10.26.2026

2 unitstock Calgary (T2C 1Z6)

Product Attributes

Technical Description

Reviews

Holder Style

Solid Carbide

Tool Diameter, Inch

1/2 (0.5)

Overhang

Standard

Insert Size

DCMT 21.5

Coolant supply

External

Min. Bore Diameter, Inch

0.728

Total Length, inch

Lead Angle

93°

Unit System

Inch

Brand

EASYCUT

Item type

Lathe Boring Bars

Technical Description

E08K-SDUCR-2 Boring Bar Drawing

A 1/2" mini boring bar for DCMT 21.5 inserts, right hand, with a 93° lead angle. The 55° insert point follows a profile — a stepped bore, a radius at the bottom of a hole, an entry chamfer — and the 1/2" carbide shank gives it reach: about three times stiffer than steel, it holds size where a steel 1/2" bar starts to chatter.

Dimensions

Shank diameter: 0.500" (12.7 mm), with a ground clamping flat
Overall length: 5.000" (127 mm)
Head length: 1.125" (28.6 mm)
Minimum bore: 0.728" (18.5 mm)
Lead angle: 93°, right hand
Insert: DCMT 21.5, DCGT of the same size also fits
Coolant: external
Included: Torx clamping screw. T-8 key not included.

Inserts for this bar

Any DCMT 21.5 insert fits the seat, whatever the corner radius. The DCMT 21.51 HE3 semi-finish insert for steel, 0.016" radius, covers general boring and profiling. At full reach a smaller radius is safer, because it pushes the bar less sideways. For aluminum, a ground DCGT insert with a sharp edge cuts with less force.

DCMT or CCMT

Take the 55° insert when the bore has a shape to follow. For plain straight bores, the 1/2" bar for CCMT 21.5 inserts has the stronger 80° corner and enters smaller holes, from 0.512".

How far it reaches

Keep the stick-out within about six times the shank diameter — roughly 3" — for a clean bore. For profiled holes between 0.610" and 0.728", the 3/8" bar for the same insert fits where this one does not. For bores of 0.945" and up that need more than 3" of reach, an anti-vibration boring bar cuts at 10 times its diameter.

Clamping

Clamp the bar in a boring bar holder on the turret; a split sleeve adapts it to a holder with a larger bore. The ground flat goes under the clamping screw — it locks the rotation of the bar and keeps the insert on center height.
